8XLPTLSS Replacement Parts

CalloutQty NeededNamePart No.PriceBuy
21Kurt Nut w/ Internal Brush Seal - 3800V-33800V-3$120.00
132Kurt Screw,SHCS,3/4-10 X 2-3/4 - 00-151900-1519$5.00
122Kurt Screw,SHCS,1/2-13 X 2-1/2 - 00-142500-1425$4.00
221Kurt Screw Support - 8XLPTLSS-224A8XLPTLSS-224A$84.00
41Kurt Screw - 8XLPTLSS-58XLPTLSS-5$596.00
251Kurt Chip Guard - 8XLPTLSS-2498XLPTLSS-249$27.00
262Kurt Truarc Retaining Ring - 8XLPTLSS-2178XLPTLSS-217$4.00
51Kurt Holding Block - 8XLPTLSS-2128XLPTLSS-212$875.00
232Kurt Retaining Ring - 8XLPTLSS-1478XLPTLSS-147$5.00
34Kurt Internal Brush Seal - PT800-211PT800-211$8.00
201Kurt Movable Jaw - D810-2D810-2$279.00
191Kurt Spherical Segment - D80-9D80-9$6.00
172Kurt Jaw Plate, 8" - D80-7D80-7$100.00
81Kurt Thrust Bearing - D80-41D80-41$4.00
241Kurt Handle Assembly - D80I-10-SAD80I-10-SA$70.00
61Kurt O-Ring, Buna N, #117 - 3600V-993600V-99$3.00
72Kurt Thrust Washer - 3600V-423600V-42$4.00
91Kurt O-Ring, Buna N #129 - 3600V-1283600V-128$3.00
211Kurt Screw, SHSS, 5/8-11 UNRC X 1-1/4 - 01-395301-3953$14.00
162Kurt Screw, SHCS, 5/8-11 X 2-1/4 - 00-148600-1486$4.00
184Kurt Screw, SHCS, 5/8-11 X 1-1/4 - 00-148100-1481$4.00
114Kurt Screw, SHCS, #8-32 X 3/8 - 00-119100-1191$3.00
